Power:
49 - 69 kW
169.000 - 235.000 Btu/h
42.100 - 59.340 Kcal/h
| Air displacement: | Fuel consumption: | Pressure: | Dimensions (l x w x ht): |
| 2.300 m3/h | 5,02 kg/h | 0,75 - 1,5 bar | 770 x 310 x 510 mm |
| Power supply: | Rated current: | Thermostat control: | Net / gross weight: |
| 230/50 V/Hz | 1,0 A | no | 14,4 / 16,8 kg |
| Ignition: | Model DV: | Pallet: | |
| piezo | dual voltage | 16 pcs |
Main features
Model descriptionMotor with thermal protection Overheat thermostat Variable heat Durable external powder coating Strong and long lasting construction Housing remains cool to the touch Dual voltage | ||
How it worksConbustion system - air flow  | RememberVentilation of the room is neccessary to prevent a deficiency in oxygen supply. Useful linksDownload catalogue |
